Fusion | SKU:
29_29.842.01
Garmin Fusion 140W 2-Channel Marine Amplifier 010-02569-00
€195,99
Unit price
/
Unavailable
Tax included
Shipping calculated at checkout.
Garmin Fusion 140W 2-Channel Marine Amplifier 010-02569-00 is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Need help? Contact us
Need help? Contact us
Delivery and Shipping
Delivery and Shipping
We ship within 24-72 business hours, depending on the product. We use national and international couriers. Express insured shipping.
Garmin Fusion 140W 2-Channel Marine Amplifier 010-02569-00
€195,99
Unit price
/
Unavailable
The Garmin Fusion 140W 2-Channel Marine Amplifier is an amplifier from Garmin's FUSION Apollo series.
Built to last in the harsh marine environment, it is characterised by excellent performance and unparalleled humidity resistance.
The amplifier is also Class D for greater energy efficiency despite excellent power.
The amplifier is also Class D for greater energy efficiency despite excellent power.
MAIN FEATURES
- Allows you to expand the audio zones on your boat — useful if you want to distribute the sound across multiple areas
- It delivers high-quality audio with low distortion for marine-ready performance.
- Relatively simple installation thanks to included mounting brackets and pre-wired wiring
- Designed for marine environments: robustness and compatibility with nautical systems (salt, humidity, vibrations, etc.) like all Fusion products
TECHNICAL DATA
- Amplifier class: Class-D
- Configuration: Zone version / 2-channel (audio zone)
- Peak power: 140W
- Rated power (RMS) at 4 Ω: 20 W x 2 channels @ 14.4 V input, < 1% THD
- Rated power (RMS) at 2 Ω: 30 W x 2 channels @ 14.4 V input, < 1% THD
- Operating supply voltage: 10.8 – 32 V DC
- Input impedance: 9 kΩ
- Input sensitivity: 0.45V RMS
- Dimensions (without bracket): ≈ 100 × 100 × 40 mm (3.94″ × 3.94″ × 1.57″)
- Dimensions (with bracket): ≈ 100 × 115 × 48 mm (3.94″ × 4.53″ × 1.89″)
- Weight: ≈ 460 g (1.01 lb)
- Protection rating: IPX7 (zone amplifier version) — water resistant to marine standards
- Protections included: reverse voltage protection, input over/under voltage, over temperature, output short circuit protection
- Ignition Protection: Complies with marine ignition safety standards (ignition protected, SAE J1171)
ADVANTAGES
- Ideal for increasing the power and quality of audio on boats, yachts or vessels — especially when you have multiple speakers/subwoofers distributed in different areas
- It allows flexible management of audio zones : you could connect multiple speakers or subwoofers, adapting the system to your listening needs
- Excellent complement if you already own “marine-ready” components such as speakers or stereos from the Fusion family
